Ubiquiti USW-Pro-Max-16-PoE UniFi 16 Port Pro Max UB.USW.PRO.MAX.16POE

Elevate your network infrastructure with the Ubiquiti UniFi USW-Pro-Max-16-PoE, a cutting-edge 16-port Layer 3 Etherlighting™ switch designed for high-performance and intelligent network management. This robust switch features advanced PoE capabilities, including four 2.5GbE PoE++ ports and twelve GbE PoE+ ports, providing a total 180W PoE budget to power your demanding UniFi devices like access points and cameras. Its silent, fanless cooling system ensures quiet operation, making it ideal for various deployment environments from small offices to larger enterprise networks.

Experience unparalleled network visibility and streamlined troubleshooting with the innovative Etherlighting™ technology. The ports illuminate to clearly indicate their location, current speed/link status, and native VLAN/network, simplifying identification and configuration at a glance. This intuitive feature, combined with a 1.3" touchscreen display for quick status checks and a comprehensive suite of Layer 2 and Layer 3 switching features, makes the USW-Pro-Max-16-PoE a powerful and user-friendly solution for modern network demands.

Designed for versatility, the UniFi Pro Max 16 PoE supports multiple mounting options including desktop, wall, and with an optional accessory, rack mounting. Its durable SGCC steel enclosure ensures longevity and reliability. Manage your entire network effortlessly through the UniFi Network application (version 8.1.127 and later), providing centralised control and advanced configuration options for a seamless UniFi experience.

FEATURES

• 16-port Layer 3 Etherlighting™ switch
• Etherlighting™ ports illuminate for visual indication of port status
• (4) 2.5GbE PoE++ RJ45 ports
• (12) GbE PoE+ RJ45 ports
• (2) 10G SFP+ ports for high-speed uplinks
• 180W total PoE availability
• Silent, fanless cooling system
• 1.3" touchscreen display for quick status updates
• Versatile desktop, wall, and rack mounting (rack mount accessory sold separately)
• Managed by UniFi Network application (version 8.1.127 and later)
• Comprehensive Layer 2 and Layer 3 switching features

SPECIFICATIONS

• Dimensions: 325.1 x 160 x 43.7mm
• Weight: 2.1kg
• Enclosure Material: SGCC steel
• Management Interface: Ethernet In-Band
• Networking Interface: (12) GbE RJ45 ports, (4) 1/2.5GbE RJ45 ports, (2) 10G SFP+ ports
• PoE Interface: (12) PoE/PoE+, (4) 60W PoE++
• Total Non-Blocking Throughput: 42Gbps
• Switching Capacity: 84Gbps
• Forwarding Rate: 62.496Mpps
• Power Method: DC adapter
• Power Supply: 54V, 210W
• Max. Power Consumption: 30W (Excluding PoE output)
• Max. PoE Wattage per Port by PSE: PoE: 15.4W, PoE+: 30W, PoE++: 60W
• Voltage Range PoE Mode: PoE: 44—57V, PoE+/PoE++: 50—57V
• LCM Display: (1) 1.3" touchscreen
• Button: Factory reset
• Ambient Operating Temperature: -5 to 40°C
• Ambient Operating Humidity: 10 to 90% noncondensing
• Certifications: CE, FCC, IC
• Layer 2 Features: IGMP snooping, STP/RSTP, Port isolation, Storm control, Voice VLAN, Port mirroring, LACP, Multicast/broadcast rate limiting, MAC address blocking, Flow control, 802.1X control, Jumbo frames, Proprietary loop protection, DHCP snooping/guarding, Egress rate limit, LLDP-MED, Port restricted by MAC, Device isolation with ACLs
• Layer 3 Features: DHCP for locally-managed networks, DHCP relay, Inter-VLAN routing, Static routing, Network isolation with ACLs

WARRANTY

1-Year Limited Warranty
