TP-Link SG2206MP Omada Access 6 Port Gigabit RJ45 ports and 1 006.008.0206

The TP-Link Omada SG2206MP is a high-performance 6-Port Gigabit Access Switch designed to power and connect your business network with efficiency. Featuring four PoE+ ports with a 63W total power budget, it simplifies the deployment of IP cameras, access points, and VoIP phones by delivering data and power over a single cable. The inclusion of an additional Gigabit RJ45 port and a dedicated SFP slot ensures flexible high-speed uplinks for diverse networking environments.

Equipped with advanced L2+ features like Static Routing, this switch optimises internal traffic and enhances network efficiency. Robust security protocols, including IP-MAC-Port Binding, ACLs, and 802.1X authentication, provide enterprise-grade protection against common network threats. Its fanless design ensures silent operation, making it an ideal choice for noise-sensitive environments like offices, classrooms, or retail spaces.

Integration with the Omada Software Defined Networking (SDN) platform offers 100% centralised cloud management. This allows for seamless monitoring and configuration via the web or the Omada app, supporting features like Zero-Touch Provisioning and intelligent monitoring. Whether managed through the cloud or as a standalone device via CLI or SNMP, the SG2206MP provides the scalability and reliability required for modern professional networks.

Housed in a durable metal casing, the SG2206MP is built for longevity and supports both desktop and wall-mount installations. With energy-efficient technology and a high packet forwarding rate of 8.93Mpps, it delivers consistent performance without high power overheads. This switch is the perfect compact solution for businesses seeking a powerful, manageable, and silent networking hub.

FEATURES

• 4x Gigabit PoE+ ports and 1x Gigabit RJ45 port
• 1x Gigabit SFP slot for high-speed fiber uplinks
• 63W total PoE budget with up to 30W per port
• Integrated into Omada SDN for centralised cloud management
• Static Routing for efficient internal traffic handling
• Fanless design for silent, distraction-free operation
• Durable metal casing with desktop or wall-mount support
• Advanced security features including ACL, 802.1X, and Storm Control

SPECIFICATIONS

• Interface: 4x 10/100/1000Mbps PoE+ RJ45 Ports, 1x 10/100/1000Mbps RJ45 Port, 1x Gigabit SFP Port
• PoE Standard: 802.3af/at
• PoE Power Budget: 63W
• Switching Capacity: 12Gbps
• Packet Forwarding Rate: 8.93Mpps
• MAC Address Table: 8K
• Packet Buffer: 4.1Mbit
• Jumbo Frame: 9KB
• Power Supply: 53.5VDC/1.31A
• Max Power Consumption: 73.7W (with 63W PD connected)
• Dimensions: 158x100.7x25.4mm
• Mounting: Desktop or Wall Mount
• Operating Temperature: -5°C to 40°C
• Surge Protection: 6kV (Ethernet ports)
• Certifications: CE, FCC, RoHS

WARRANTY

1-Year Limited Warranty
